AR-15 Disconnector

AR-15 Disconnector

The disconnector is the small part in an AR-15 trigger group that lets the rifle fire one shot per trigger pull. After each shot it catches the hammer as the bolt carrier cycles. When you let the trigger forward to reset, it hands the hammer back to the trigger sear. This United Defense disconnector is a replacement for a worn, damaged or lost part, and a sensible spare to keep on the bench if you build or maintain your own rifles.

Features

• AR-15 Fire Control Part — Made for the AR-15 fire control group, the trigger, hammer and disconnector assembly that sits inside the lower receiver.
• Hammer Catch Hook — The curved hook on top grabs the hammer after each shot so it cannot follow the bolt forward until the trigger is released.
• Trigger Pin Pivot Hole — A round hole through the body lets the disconnector ride on the trigger pin and pivot inside the trigger slot.
• Standard AR-15 Profile — The flat, single-piece shape matches the familiar AR-15 disconnector pattern shown in the photograph.
• Black Finish — A dark finish covers the part, which is typical for internal AR-15 fire control components.
• Semi-Automatic Function — This is the part that resets the action after every round, giving the AR-15 its one-shot-per-pull operation.
• Single Replacement Part — The listing covers the disconnector itself, so you can replace that one component without buying a full trigger kit.
• United Defense Brand — A commercial-manufacture part from United Defense rather than military surplus.

Fit and Installation

The disconnector sits in a slot in the trigger body, held on the same pin as the trigger and pushed up by its own small spring, which is a separate component. To install it, drift out the trigger pin, fit the disconnector and spring into the trigger, and reassemble. Drop-in cassette triggers use their own internal disconnectors, so this part is meant for rifles running a conventional separate-component trigger group. Always function-check the rifle after any fire control work.
