AR-15 Pivot Pin Detent

AR-15 Pivot Pin Detent

The pivot pin detent is the small pin that holds your AR-15's front takedown pin in place. It sits in a channel at the front of the lower receiver, and its spring pushes it into the groove on the pivot pin so the pin stays put until you push it out to separate the upper and lower. Detents are tiny and easy to lose during a build or a cleaning session, and this United Defense part replaces one that went missing or wore out.

Features

• Front Pivot Pin Retention — Spring pressure holds the detent in the pivot pin's groove, keeping the upper and lower receivers hinged together while you shoot.
• Tapered Ends — Both ends are cone-shaped with a small flat tip, so the detent rides into and out of the pivot pin groove smoothly.
• Symmetrical Design — Because both ends share the same profile, the detent drops into its channel either way round.
• Dark Finish — The pin carries a dark, matte finish that matches the parts around it on a standard black lower.
• Standard AR-15 Pattern — Built to the common AR-15 pivot pin detent layout used in mil-spec pattern lower receivers.
• Lower Parts Kit Replacement — A single detent to replace one lost from a lower parts kit, so you do not need to buy the whole kit again.
• United Defense Manufacture — Produced by United Defense, a commercial maker of AR-15 components.

Fit And Installation

The detent works with the pivot pin detent spring and the front pivot pin in a standard AR-15 lower receiver. The spring goes into the channel first and the detent follows, then you hold the detent compressed while the pivot pin slides past it. The spring is strong for the size of the parts, so work inside a clear plastic bag or use a pivot pin install tool to stop the detent flying across the room.
